USE FOR : SANY SY956 loader air condiction spare parts
Part NO. 60309960 , 60270027
| INDEX | PART NUMBER | QTY | PART NAME |
| 13511972 | AIR CONDICTION SYSTEM | ||
| 1 | A210111000090 | 6 | Bolt |
| 2 | A210111000093 | 4 | Bolt |
| 3 | 24000511 | 11 | Washer |
| 4 | 60060565 | 8 | Washer |
| 5 | 13049726 | 2 | BRACKET |
| 6 | A210307000012 | 5 | Nut |
| 7 | 60272643 | 1 | hose |
| 8 | 60270027 | 1 | CONDENSER |
| 9 | 60272647 | 1 | hose |
| 10 | 60269907 | 2 | CONNECTOR |
| 11 | 60272648 | 1 | hose |
| 12 | A210111000195 | 8 | Bolt |
| 13 | 24000637 | 8 | Washer |
| 14 | 60086357 | 8 | Clamp |
| 15 | 60270026 | 1 | EVAPORATOR |
| 16 | 60234587 | 1 | Control panel |
| 17 | 60234588 | 1 | Harness wire air conditioner |
| 18 | A239900000065 | 20 | Nylon belting |
| 19 | 60272644 | 1 | hose |
| 20 | 60272646 | 1 | HOSE |
| 21 | 13511971 | 1 | BRACKET SYL956H5.12.1 |
| 22 | 60235423 | 1 | A/C Compressor |
| 23 | 60279718 | 1 | BELT |
| 24 | 60086353 | 2 | the fixity of line |
| 25 | 60086355 | 3 | the fixity of line |
| 26 | 60149606 | 1 | Clamp |
| 27 | 60149607 | 1 | The Fixity Of Line |
| 28 | 60272649 | 1 | water Valve |
| 29 | 61001033 | 1 | Water valve |
| 30 | 13511238 | 1 | plate |
| 31 | A210307000017 | 2 | Nut |
| INDEX | PART NUMBER | QTY | PART NAME |
| 60270026 | EVAPORATOR | ||
| 1 | 60309971 | 1 | BRACKET |
| 2 | 60309972 | 1 | FILTER |
| 3 | 60309955 | 1 | BOX |
| 4 | 60309973 | 1 | HARnESS |
| 5 | 60309974 | 1 | RELAY |
| 6 | 60309963 | 1 | FAN |
| 7 | 60309962 | 1 | HEATER |
| 8 | 60309961 | 1 | DETECTOR |
| 9 | 60309960 | 1 | COOLER |
| 10 | 60309964 | 8 | CLAMP |
| 11 | 60309956 | 2 | HOSE |
| 12 | 60309958 | 1 | WATER VALVE |
| 13 | 60309959 | 1 | CONNECTOR |
| 14 | 60309957 | 1 | HOSE |
| 15 | 60309965 | 1 | CONNECTOR |
| 16 | 60309966 | 1 | CONNECTOR |
| 17 | 60309967 | 1 | HOSE |
| 18 | 60309969 | 1 | VALVE |
| 19 | 60309970 | 1 | TIE |
| 20 | 60309968 | 1 | HOSE |
